GTM Coupe



The specifications of the GTM Coupe



    • FEATURES

    Technical Specification

    Length

    130"

    Width

    57"

    Wheelbase

    84"

    Height

    42"

    Ground Clearance

    5"

    Weight (Road Trim)

    630kg

    Engine

    A-Series 850-1275cc (modified up to 1340cc)

    Gearbox

    Standard 4-speed (aftermarket 5-speed available)

    Body Type

    2 Seater mid-engined coupe

    Chassis Type

    Fabricated steel semi-monocoque chassis with unstressed fibreglass body

    Suspension Type

    Mini rubber cone (ride height adjustable via hi-lo units)

    Braking System

    Option of all drum brakes, all disk or disks front/drums rear

    The Coupe was later built by Hambly Sports Cars Limited www.hamblysportscars.co.uk

    The design was carefully modified to allow the Coupe to pass the SVA test.
